MPPT 30–60A · IP65Controller
Euronet MPPT Controller
Intelligent Solar Charge Management. Advanced MPPT solar charge controller with IP65 protection, up to 97.6% efficiency, color LCD display, and RS485/RJ45 communication for professional solar installations.
TypeMPPT
Rated Current30A / 40A / 50A / 60A
Max PV Voltage150V (138V at 25°C)
ISO 9001:2015 Certified · Trusted in 60+ Countries
Key Features
Built for Reliability
Multi-Stage Charging
MPPT, absorption, float, and equalization charging modes optimize battery health and extend cycle life.
Up to 97.6% Efficiency
Advanced power conversion minimizes energy loss, delivering more of your solar harvest to the battery bank.
Multi-Battery Support
Compatible with gel, SLD, FLD, USR, and lithium battery types with customizable charging profiles.
Color LCD Display
Backlit color display with 3-button interface shows real-time PV input, battery status, and load information.
Specifications
Technical Details
TypeMPPT
Rated Current30A / 40A / 50A / 60A
Max PV Voltage150V (138V at 25°C)
System Voltage12V / 24V / 36V / 48V Auto
Max Efficiency97.6%
MPPT Accuracy99%
IP RatingIP65
DisplayColor LCD with backlight
CommunicationRS485, RJ45
Battery TypesGel, SLD, FLD, USR, Lithium
CoolingAL alloy heat sink + cooling fan
Operating Temp-20°C to +55°C
Dimensions222 × 200 × 85mm (30/40A)
Weight2500g (30/40A) / 3500g (50/60A)
Product Highlights
- Up to 97.6% charging efficiency — best-in-class MPPT
- IP65 rated for outdoor and harsh environment installations
- Color LCD with backlight and 3-button interface
- DC/AC surge protection and reactive power controller
- RS485 and RJ45 communication for system monitoring
