Solar Batteries

EURONET Lithium Battery 51.2V 314Ah IP65

The EURONET E-NEO314/51.2V-IP65 is a floor-standing 51.2V LiFePO4 battery for residential solar energy storage. It stores 16.08kWh (314Ah) and delivers up to 10.0kW of maximum discharge power, working with a hybrid inverter to store excess solar energy for use in the evening and at night. A built-in BMS with triple hardware protection, CAN/RS485 inverter communication and WiFi monitoring through the Smart Energy PLAT app are housed in an IP65 metal enclosure. Up to 8 identical units can be connected in parallel to expand capacity.

ModelE-NEO314/51.2V-IP65

ChemistryLiFePO4 (lithium iron phosphate)

Nominal voltage51.2 V

Download Datasheet Request a Quote

ISO 9001:2015 Certified · Trusted in 60+ Countries

Specifications

Technical Details

Technical Details
Model	E-NEO314/51.2V-IP65
Chemistry	LiFePO4 (lithium iron phosphate)
Nominal voltage	51.2 V
Voltage range	48 V – 56 V
Capacity	314 Ah
Energy	16.08 kWh
Max discharge power	10.0 kW
Design cycle life	8,000 cycles
BMS	Built-in, triple hardware protection
Protection	Over-current, over-voltage, short circuit, under-voltage, over-temperature
Communication	CAN / RS485
Wireless monitoring	WiFi (2.4 GHz) via Smart Energy PLAT app
Display	LCD
Parallel	Up to 8 units (same batch and specification)
Operating temperature	Charge -10°C to 70°C; discharge -20°C to 70°C
Optimal operating temperature	15°C to 30°C
Relative humidity	0 to 95% RH (non-condensing)
Altitude	≤ 2,000 m
IP rating	IP65
Installation	Floor-standing, indoor
Cooling	Ambient cooling
Dimensions (W × D × H)	564 × 156 × 960 mm
Enclosure	Metal, protective class I
Certification	CE, CB
Transport	UN38.3 tested; UN3480 as applicable
